Introduction

Many users face this puzzling situation: the load is within the rated capacity, yet the transformer is alarmingly hot – the enclosure is too hot to touch, oil temperature alarms keep triggering, and trips occur frequently.

This is not caused by overload, but the problem may be even more hidden. This article focuses on 5 hidden causes of abnormal heating when the load is normal – issues that are often overlooked but can be just as damaging.

1️⃣ Cause 1: Core Insulation Damage – Eddy Current Heating

Problem description:
A transformer core is made of stacked silicon steel sheets, with insulation between each sheet. If the insulation ages or breaks down, eddy currents “run wild” inside the core, generating excessive heat.

Why does it overheat even under normal load?
Core losses (eddy current + hysteresis) exist even at no load. Once core insulation is damaged, these losses multiply – but the load current may appear completely normal.

How to tell:

• No‑load current increases significantly

• The transformer runs hot even with no load

• Oil chromatography shows abnormally high acetylene or methane

Solutions:

• Return to factory for core repair or replacement

• Cannot be repaired on site

✅ Recommendation: Perform regular oil chromatography to detect core issues early.

2️⃣ Cause 2: Local Winding Short Circuit (Turn‑to‑Turn Short)

Problem description:
Adjacent conductors inside the winding come into contact, creating a local short circuit. This generates a large current in the shorted loop, causing severe local overheating.

Why does it overheat even under normal load?
A local short may involve only a few turns – the overall current changes little, but the local temperature becomes extremely high, accelerating insulation aging and potentially burning the transformer.

How to tell:

• Abnormal “humming” or “buzzing” (discharge) sound inside the transformer

• Buchholz (gas) relay operates

• Winding DC resistance is unbalanced (>2% difference between phases)

Solutions:

• Stop operation immediately for inspection

• Replace the faulty winding or rewind

✅ Recommendation: Test winding DC resistance annually.

3️⃣ Cause 3: Low Oil Level or Deteriorated Oil Quality (Oil‑Immersed Transformers)

Problem description:
In oil‑immersed transformers, the oil is not only an insulating medium but also a cooling medium. Low oil level or degraded oil quality reduces heat dissipation capacity.

Why does it overheat even under normal load?
When oil level is low, heat cannot transfer effectively to the radiators. When oil quality deteriorates (high moisture content, acidity), both insulation and thermal conductivity decline.

How to tell:

• Oil level gauge shows below normal

• Oil color has darkened, become cloudy, or has a strange odor

• Oil withstand voltage test fails

Solutions:

• Top up oil to normal level

• Filter or replace the transformer oil

✅ Recommendation: Perform oil sampling annually, and filter or replace oil every 3–5 years.

4️⃣ Cause 4: Blocked Radiators or Fan Failure

Problem description:
Transformer radiators are covered with dust, sludge, or debris, or the forced cooling fans are not running or are running too slowly.

Why does it overheat even under normal load?
With the heat dissipation path blocked, heat cannot escape – even under moderate load, temperature will gradually build up.

How to tell:

• Radiators feel cool, but the top of the tank is very hot

• Fans are not running or run abnormally slowly

• Radiator surfaces have thick dust or sludge buildup

Solutions:

• Clean radiators with high‑pressure air or water (after disconnecting power)

• Inspect fan motors and replace faulty components

✅ Recommendation: Clean radiators every six months and inspect fans annually.

5️⃣ Cause 5: High Ambient Temperature or Poor Ventilation

Problem description:
The transformer is installed in a confined electrical room, an outdoor compact substation, or with blocked vents – ambient temperature is much higher than the design value.

Why does it overheat even under normal load?
Transformer cooling relies on temperature difference. The higher the ambient temperature, the slower the heat dissipation. When ambient temperature exceeds 40°C, the transformer may overheat even under normal load.

How to tell:

• The electrical room is significantly hotter than the outside

• Insufficient clearance around the transformer

• Vents are blocked by debris

Solutions:

• Add exhaust fans or air conditioning

• Clear vents and increase clearance around the transformer

• Move the transformer to a better‑ventilated location

✅ Recommendation: For indoor installations, forced ventilation must be designed into the electrical room.

6️⃣ Quick Troubleshooting Checklist ✅

Conclusion

Normal load does not guarantee that a transformer will not overheat. Core damage, winding shorts, oil quality issues, blocked heat dissipation, and high ambient temperature – these 5 hidden causes can be just as deadly.

Recommended regular inspections:

• Annually: Oil sampling, DC resistance test

• Every six months: Clean radiators, check fans

• Every quarter: Check oil level, listen to operating sound

Early detection and timely action will keep your transformer running reliably for 20+ years.

If the problem persists after troubleshooting, contact a professional technician for thermal imaging or factory inspection.
